To provide satellite users with a variety of life cycle, flexible mode of in-orbit management services.

Laser Satellite Calibration and Inspection Service


Geometric calibration and accuracy verification for satellite laser altimetry payload


Service Introduction

The geometric calibration of spaceborne laser mainly detects the laser signal emitted by the satellite to the surface through the calibration field, accurately obtains the position of the laser spot, detects the energy distribution of the laser spot, and calibrates the installation of the laser operating in space and the energy distribution of the emitted laser in order to correct the laser measurement data obtained on the satellite.

Emposat

Technical Parameters

Compatible with joint calibration of 1064nm and 532nm lidar;

Position calibration accuracy of laser footprint spot: better than 2m;

The device terminal has an effective quantization level of 16 bits;

Laser altimeter calibration accuracy: better than 0.05m;

Time synchronization error of laser receiving signal: better than 0.1ms;





Manual

Purchase spaceborne laser geometric calibration service and fill in the parameters


01

satellite transit, laser geometric calibration equipment work


02

user provides optical satellite transit images


03

Emposat submits data processing report


04
